    Industrial Wrinkle Finish Powder Coat , RAL 1004 Automotive Pearl Pigment Powder

    Ask Lasest Price
    Brand Name : TOPO
    Model Number : PPC-RAL1004
    Certification : CE, BV, ROHS
    Price : Negotiable
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 400 T/Month
    Delivery Time : 7 days
    • Product Details
    • Company Profile

    Industrial Wrinkle Finish Powder Coat , RAL 1004 Automotive Pearl Pigment Powder

    RAL1004 golden yellow Environmentally Friendly pearl powder coating for appliance industry


    The appliance industry benefits from powder coating on front and side panels of ranges and refrigerators, washer tops and lids, dryer drums, air-conditioner cabinets, water heaters, dishwasher racks, and cavities of microwave ovens.

    Powder coating has also replaced porcelain enamel on many washer and dryer parts.


    Test Item

    Test Standard

    Smooth finish

    Texture finish

    Gloss (60°)

    ISO2813

    15~85 unit

    3~15 unit

    Film thickness

    ISO2360

    60~80 microns

    70~90 microns

    Adhesion (1mm)

    ISO2409

    0 level

    0 level

    Pencil hardness

    ISO15184

    ≥2H

    ≥2H

    Cupping

    ISO1520

    ≥5mm

    ≥5mm

    Mandrel bend

    ISO1519

    ≤5mm

    ≤5mm

    Impact ( 20 inch.lbs)

    ASTMD-2794

    Direct and reverse pass

    Direct and reverse pass

    Humidity (1000hrs)

    ISO6270-1

    Max. blistering less than 1mm

    Max. blistering less than 1mm

    Salt pray (1000hrs)

    ISO9227

    Max. blistering less than 1mm

    Max. blistering less than 1mm


    ItemStandardResults
    ImpactGB/T1732-199350cm
    Cupping TestGB/T9753-19886mm
    AdhesionGB/T9286-19980 Grade
    BendGB/T6742-19863mm
    Pencil HardnessGB/T6739-19961H-2H
    Salt SprayGB/T1771-1991>500hrs
    HumidityGB/T1740-1989>1000hrs
    Remarks :1. Tests are carried out on 0.8mm steel panel with film thickness of 60 microns.
    2. Some types of color may have the reduced properties.

    TOPO Powder Coating is a full service powder coating and industrial abrasive blasting and surface preparation company. For over 20 years, we have provided excellent service for our customers serving Maryland, Delaware, Virginia and Southern Pennsylvania region. Our trained and dedicated specialists are among the most experienced and knowledgeable in the industry.

    Our process produces an environmentally-friendly, uniform, durable, high-quality and attractive finish.
