RAL1001 beige Insulating Epoxy Coating for single conductors

In need of insulated copper or aluminum conductors for tight-fitting, durable bus systems, Storm Power Components provides the expertise, capabilities and equipment to manufacture high dielectric, epoxy powder-coated bus bar.

Epoxy Powder-Coated Insulation offers a high dielectric strength while creating durable insulation, impervious to most elements allows for closer busbar location in a system ideal for single conductors or multiple conductor assemblies that may have numerous forms. Epoxy powder coating is also well suited for insulating thick conductors, in addition to conductors with multiple electrical contact points.

Epoxy powder coating is a free-flowing, thermosetting dry powder. Think of this process as a way of "melting" paint over a bisbar's surface to create a durable, protective surface with thickness ranging from 6 to 120 mils or .006 to .120 inches. When the epoxy powder cures, a cross-link occurs increasing molecular weight and insulation capability.

Epoxy powder is chemical resistant and one of the oldest powder paints used in the electronics industry. It not only protects against corrosion but carries a high insulation rating of 800 volts per mil (.001 inches) at a minimum of 10 mil (.010 inches). Due to safety consideration it is recommended that a High-Pot test is preformed rather than rely on film thickness.
Tensile strength on raw and plated copper bar is in the range of 7500 PSI. UL rating is 130 Cº. Epoxy powder coating's high dielectric strength can be varied based on the application process, thickness and component preparation.

Jinhu Color Powder Coating Co.,Ltd with brand FEIHONG founded in 1993,is a rapid growing enterprise who integrate the production and marketing of thermoset powder coating.After 28 years' effort and development,now we have become one of the leading powder coating,powder paint manufactures and suppliers in China.

We are always keeping kind relationship with our distributors and end users around the world,and enjoy high reputation in powder coating industry domestically and internationally.

Feihong factory focus on formulating kinds of electrostatic powder coatings,which include epoxy,epoxy polyester (Hybrid),pure polyester,polyurethane powder coating for indoor,outdoor application.With advanced production lines and professional technology,besides the regular powder paints,we do very well in bonding powder paint,metallic powder paint and textured powder paint,which are widely used in metal surface coating for decorative and protective purpose.The products are successfully exported to more than 48 countries.

But Feihong have never stop going forward,in order to control the cost and supply competitive price,better in-time service for our European customers,in 2017 we built another factory in Europe,which is for producing powder coating and exibiting the color sample panels to customers nearby.

For meeting customers' specific color requirements,color matching and tailor-made service are provided before placing bulk order.

We take "Quality, Service, Innovation, Efficiency" as a market philosophy, and introduce the first-class equipment, advanced testing device to ensure output prenium products, and serve all customers with best and instant service .

Continuous quality improvement in products is FEIHONG's only goal to meet and exceed customer expectations.
