RAL1027 curry electrostatic thermoset powder coating for Construction Equipment

Electrostatic Fluidized Bed Coating: Electrostatic fluidized bed application uses the same fluidizing technique and the conventional fluidized bed dip process but with much less powder depth in the bed. An electrostatic charging media is placed inside the bed so that the powder material becomes charged as the fluidizing air lifts it up. Charged particles of powder move upward and form a cloud of charged powder above the fluid bed. When a grounded part is passed through the charged cloud the particles will be attracted to its surface. The parts are not preheated as they are for the conventional fluidized bed dip process.

Electrostatic magnetic Brush (EMB) Coating: an innovative coating method for flat materials that applies powder coating with roller technique, enabling relative high speeds and a very accurate layer thickness between 5 and 100 micrometre. The base for this process is conventional copier technology . Currently in use in some high- tech coating applications and very promising for commercial powder coating on flat substrates ( steel, Aluminium, MDF, paper, board) as well in sheet to sheet and/or roll to roll processes. This process can potentially be integrated in any existing coating line.

Curing
When a thermoset powder is exposed to elevated temperature, it begins to melt, flows out, and then chemically reacts to form a higher molecular weight polymer in a network-like structure. This cure process, called crosslinking, requires a certain degree of temperature for a certain length of time in order to reach full cure and establish the full film properties for which the material was designed. Normally the powders cure at 200°C (390°F) in 10 minutes. The curing schedule could vary according to the manufacturer's specifications.

The application of energy to the product to be cured can be accomplished by convection cure ovens or infrared cure ovens.

Suit your widest needs

Jinhu Color Powder Coating Co.,Ltd with brand FEIHONG founded in 1993,is a rapid growing enterprise who integrate the production and marketing of thermoset powder coating.After 28 years' effort and development,now we have become one of the leading powder coating,powder paint manufactures and suppliers in China.

We are always keeping kind relationship with our distributors and end users around the world,and enjoy high reputation in powder coating industry domestically and internationally.

Feihong factory focus on formulating kinds of electrostatic powder coatings,which include epoxy,epoxy polyester (Hybrid),pure polyester,polyurethane powder coating for indoor,outdoor application.With advanced production lines and professional technology,besides the regular powder paints,we do very well in bonding powder paint,metallic powder paint and textured powder paint,which are widely used in metal surface coating for decorative and protective purpose.The products are successfully exported to more than 48 countries.

But Feihong have never stop going forward,in order to control the cost and supply competitive price,better in-time service for our European customers,in 2017 we built another factory in Europe,which is for producing powder coating and exibiting the color sample panels to customers nearby.

For meeting customers' specific color requirements,color matching and tailor-made service are provided before placing bulk order.

We take "Quality, Service, Innovation, Efficiency" as a market philosophy, and introduce the first-class equipment, advanced testing device to ensure output prenium products, and serve all customers with best and instant service .

Continuous quality improvement in products is FEIHONG's only goal to meet and exceed customer expectations.
