Brand Name : | TOPO |
Model Number : | D-RAL1001 |
Certification : | CE, BV, ROHS |
Price : | Negotiable |
Payment Terms : | L/C, T/T, Western Union, MoneyGram |
Supply Ability : | 400 T/Month |
Delivery Time : | 7 days |
RAL1001 Beige good reputation competitive hammer finish decorative powder coating paint
Product Details | |
Type | Polyester Powder Coating |
Gloss Level | Semi Gloss 90% |
Surface Finish | Wrinkle |
Powder Property | |
Appearance | Fine powder |
Particle Size | Average 32-40μm |
Specific Gravity | 1.3-1.5g/cm3 |
Coverage | 7-8 square meter per Kg at 80μm film thickness |
Application Recommendation | |
Applicatoin | Corona |
Application Voltage | 60-90 KV |
Gun to Component Distance | 15-30 CM |
Film Thickness | 80-90μm |
Curing Temperature | 190℃(Object temperature) for 15 minutes |
Powder Coated Film Mechanical Properties | |
Adhesion | Cross-cut (2mm), no loss of adhesion |
Impact Resistance | Direct & Indirect 50kg/cm |
Pencil Hardness | 2H |
Flexibility | 7mm Mandrel |
Bending Test | 3mm |
Powder Coated Film Chemical Resistance | |
Salt Spray Test | 5% NaCl Solution for 1000 hours - No change |
Acid Resistance | 5% HCL for 48 hours dip test - No change |
Alkali Resistance | 5% NaOH for 48 hours dip test - No change |
Surface Preparation | |
All surfaces shall be degreased and pre-treated for optimal performance before application | |
Aluminium | Yellow chromate or green chromate/phosphate |
Ferrous metals | Zinc phosphate or Iron phosphate |
Zinc coated metals | Zinc phosphate or choromate conversion |
Exterior Durability | |
QUV A 340 Resistance | 240 hours - 70% gloss retention |
![]() |
