RAL1000 green beige electrostatic spray thermosetting epoxy polyester Powder Coating

Powder coating is a dry finishing process where finely ground particles of pigment and resin are electrostatically charged and sprayed onto a grounded part. The part is then baked in a curing oven, at which time, the powder melts, bonds and cures – leaving an attractive, uniform, high-quality and durable finish. Prior to coating, parts are pre-treated to ensure optimal surface preparation and paint adhesion.

In addition, TOPO facilities and processes are designed to deliver Class “A” finishes.


COLORS AVAILABLE

• RAL colors coating powder
• Pantone colors
• Color-matching is available

GENERAL TYPES

• Polyester /Hybrid powder coating color
• Epoxy Powder coating color
• Metallic powder coating color
• Hammer tone color powder coating
• Texture color powder coating powder

Textures include sand grain, hammer, silk pattern, sand textured, marble,metallic, wood, multi-color.

PHYSICAL PROPERTIES

• Specific gravity : 1.2 ~ 1.8g/cm3 up to colors
• Particle size distribution: 100% less than 100 microns (depending on the specific indicators art effects may be, according to the special requirements of painting adjusted)
• Level of liquidity: 24 ~ 27 mm

CURING CONDITIONS
180 °C ~ 200 °C (work piece temperature), 10-15 minutes

AVERAGE COVERAGE
8-12 square meters / kg, thickness 60 microns (100% of the powder coating utilization rate)

PACKING
Outside carton lined with two layers of polyethylene bags, each containing 20 kg net weight.

STORAGE AND TRANSPORT
Stored in less than 30 °C, ventilated, dry, clean room, not near the fire source, heating, avoid direct sunlight, the product in the transport should be to prevent rain, sun, prolonged sun exposure. Storage products in line with the above conditions, since the date of production, effective storage period is 6 months. Over the storage period may be re-tested and the results were consistent with, can still be used.

HEALTH AND SAFETY
Coating powder is a non-toxic products, but should be avoided in the course of inhalation of dust. Proposed operators wear appropriate dust mask, glasses. If possible, try to avoid long-term skin contact with powder coating

Jinhu Color Powder Coating Co.,Ltd with brand FEIHONG founded in 1993,is a rapid growing enterprise who integrate the production and marketing of thermoset powder coating.After 28 years' effort and development,now we have become one of the leading powder coating,powder paint manufactures and suppliers in China.

We are always keeping kind relationship with our distributors and end users around the world,and enjoy high reputation in powder coating industry domestically and internationally.

Feihong factory focus on formulating kinds of electrostatic powder coatings,which include epoxy,epoxy polyester (Hybrid),pure polyester,polyurethane powder coating for indoor,outdoor application.With advanced production lines and professional technology,besides the regular powder paints,we do very well in bonding powder paint,metallic powder paint and textured powder paint,which are widely used in metal surface coating for decorative and protective purpose.The products are successfully exported to more than 48 countries.

But Feihong have never stop going forward,in order to control the cost and supply competitive price,better in-time service for our European customers,in 2017 we built another factory in Europe,which is for producing powder coating and exibiting the color sample panels to customers nearby.

For meeting customers' specific color requirements,color matching and tailor-made service are provided before placing bulk order.

We take "Quality, Service, Innovation, Efficiency" as a market philosophy, and introduce the first-class equipment, advanced testing device to ensure output prenium products, and serve all customers with best and instant service .

Continuous quality improvement in products is FEIHONG's only goal to meet and exceed customer expectations.
