    RAL 3020 Traffic Red Pure Polyester Powder Coating Fusion Bonded Epoxy Powder Coating

    Ask Lasest Price
    Brand Name : FEIHONG TOPO
    Model Number : RAL3020
    Certification : CE, ROHS, BV
    Price : Negotiable
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 400 T/Month
    Delivery Time : 7 days
    • Product Details
    • Company Profile

    RAL 3020 Traffic Red Pure Polyester Powder Coating Fusion Bonded Epoxy Powder Coating

    RAL 3020 Traffic Red Pure Polyester Powder Coating Fusion Bonded Epoxy Powder Coating


    Most powder coatings have a particle size in the range of 2 to 50 μ (Microns), a softening temperature Tg around 80 °C, a melting temperature around 150 °C, and are cured at around 200 °C. for minimum 10 minutes to 15 minutes (exact temperatures and times may depend on the thickness of the item being coated). [1] For such powder coatings, film build-ups of greater than 50 μ (Microns) may be required to obtain an acceptably smooth film. The surface texture which is considered desirable or acceptable depends on the end product. Many manufacturers actually prefer to have a certain degree of orange peel since it helps to hide metal defects that have occurred during manufacture, and the resulting coating is less prone to showing fingerprints.

    Product series

    The products include high light ( above 86%),

    glazed (76%-85%),

    matt(20%-50%),

    super matt (below 20%).

    We also offer a variety of shiny products according to the needs of users.


    Application

    Suitable for all kinds of products such as household appliances, instruments, meters medical devices,
    automotive components, metal furniture, fitness equipment, indoor decorative painting, etc.
    Also apply to a variety of equipment, pipes, pipe fittings and other requirements of corrosion coating.


    Storage requirements:

    Store below 30 °C, ventilated, dry, clean room, not near the fire, heat, direct sunlight, open dumps is prohibited.Under this condition, the powder can be stable for 12 months, more than the storage period may be re-examined, such as the results meet the requirements, can still be used.

    Health and safety:

    This product is non-toxic. In the course of inhalation of dust should be avoided. The operators should wear appropriate dust mask and glasses.

    Technic Data:

    DescriptionPowder coating
    Another NamePowder paint,Electrostatic powder coating, thermosetting powder coating
    TypePolyester resin series
    Main MaterialPolyester resin and hardner
    AdvantageGood adhesion,good mechanical property,strong coating film,
    excellent insulation,anticorrosion,energy-efficient,convenient operation.
    Application FieldApply to anticorrosive and insulative products:
    Anticorrosion pipeline,rebar,bridge,steel structure,
    pylon,tank,marine fittings,electric control cabinet,
    switch components,lighting sets.
    Application ConditionElectrostatic spray/Triboelectric gun spray.
    Recommended curing condition:200 degree centigrade for 12 minutes
    (object surface temperature),range from 190 degree centigrade
    for 20 minutes to 210 degree centigrade for 8minutes.
    Recommended film thickness:50~80um, range from 40~150um
    Physical PropertySpecific gravity1.4~1.8g/cm3 as per formula and color
    Particle sizeaverage 35~40um
    Test ConditionSubstrate0.5mm thickness cold rolled steel sheet
    PretreatmentRemove rust and grease
    Film thickness50~80um
    Curing temperature200 degree centigrade for 10 minutes
    Application FieldApply to anticorrosive and insulative products:
    Anticorrosion pipeline,rebar,bridge,steel structure,
    pylon,tank,marine fittings,electric control cabinet,
    switch components,lighting sets.
    Application ConditionElectrostatic spray/Triboelectric gun spray.
    Recommended curing condition:200 degree centigrade for 12 minutes
    (object surface temperature),range from 190 degree centigrade
    for 20 minutes to 210 degree centigrade for 8minutes.
    Recommended film thickness:50~80um, range from 40~150um
    Physical PropertySpecific gravity1.4~1.8g/cm3 as per formula and color
    Particle sizeaverage 35~40um
