    RAL 1016 Epoxy Anti Corrosion Powder Coating , Electric Protective Powder Coating

    Ask Lasest Price
    Brand Name : TOPO
    Model Number : PE-RAL1016
    Certification : CE, BV, ROHS
    Price : Negotiable
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 400 T/Month
    Delivery Time : 7 days
    • Product Details
    • Company Profile

    RAL 1016 Epoxy Anti Corrosion Powder Coating , Electric Protective Powder Coating

    RAL1016 sulfur yellow Heavy Anticorrosion Epoxy Coating powder spary paint for home electric appliance

    The raw materials of Powder coating are resins, pigments, fillers, harderner ect. Compared with lyquid paint, powder coating is environmental friendly and can reduce costs. Powder coating can form a harder finish than conventional paint and can be applied more efficient. While it also has disadvantages, it is not good for large amd heat-sensitive objects. Usually the thickness of film by powder coating is >30 um.


    Coating Specification

    Test Items

    Technical Indicators

    Test Method

    Appearance

    smooth,uniform color, no bubble , no cracking and sinkhole, allow light crack

    visual

    24h or 48h adhesion

    1~2

    SY/T 0315-2005

    24h or 48h cathodicdisbonding resistance(mm)

    ≤6

    SY/T 0315-2005

    cathodicdisbonding resistance 28d(mm)

    ≤ 8

    SY/T 0315-2005

    Porosity of bottom section

    1~4

    SY/T 0315-2005

    Porosity of underlying surface

    1~4

    SY/T 0315-2005

    2° bending resistant(0°or -30°) common level

    No cracking

    Q/CNPC38-2002 appendix D

    1.5°bending resistant(0°or-30°)Intensify Level

    No cracking

    Q/CNPC38-2002 appendixD

    10J Impact(common level)

    No pinehole

    Q/CNPC 38-2002 appendix E

    15J Impact Intensify Level

    No pinehole

    Q/CNPC 38-2002 appendix E

    scratchresistant, 30Kg,
    common level

    Scratch depth≤350μm
    No leaking point

    Q/CNPC 38-2002 appendix F

    scratchresistant,50Kg,
    Intensify Level

    Scratch depth≤500μm
    No leaking point

    Q/CNPC 38-2002 appendix F



    Notes:

    1. 1. Steel surface should be no oil and water, surface quality should reach Sa2 1/2 level (GB/T8923), anchor pattern depth 50-90mm, clean dust and abrasive attached to the steel surface

    2. 2. Product should be stored in ventilated, dry, indoor temperature below 30 ℃, away from heat, corrosive chemicals and chemical solvents, avoid bright light, the maximum stack height should not exceed 4 layers, avoid prolonged pressure, ensure airtight box. In case the clot and damp affects the fluidization performance.
