    Office Furniture Thermoset Powder Coating RAL 1016 Color 50mm Coating Thickness

    Ask Lasest Price
    Brand Name : TOPO
    Model Number : TPC-RAL1016
    Certification : CE, SGS, BV, ISO
    Price : Negotiable
    Payment Terms : Western Union, MoneyGram, L/C, T/T
    Supply Ability : 400ton/Month
    Delivery Time : 7 days
    • Product Details
    • Company Profile

    Office Furniture Thermoset Powder Coating RAL 1016 Color 50mm Coating Thickness

    RAL1016 sulfur yellow electrostatic thermoset powder coating for Office Furniture


    The fluidized bed is the original powder coating technique. It is still the primary technique used for the application of thermoplastic powders. The fluidized bed is also used for the application of some thermoset powders where high film build is required. Thermoset powders designed for electrical insulation often use the fluidized bed technique. The parts are pre-heated to a temperature significantly higher than the melting point of the powder. The parts are then immersed into a "fluidized bed" of the coating powder where the plastic powder is melted onto the part.


    Electrostatic spray is the primary technique used for thermoset powders. The particles of powder are given an electrical charge in the powder coating gun. The target part is attached to a fixture that is grounded. The electrically charged powder particles are attracted to the grounded part and attach themselves like little magnets to the part. The particles build-up on the surface of the part until it is covered with charged particles and the part surface is charged. At this point the oncoming particles are actually repelled by the charged particles on the part and the coating process stops. This provides an even film thickness.


    Thermoset Pros

    • More resistant against high temperature.
    • Hard and rigid.
    • Thin to thick wall capability.
    • Excellent appearance.
    • High mechanical property.
    • Cost effective.
    • Excellent dimensional stability.

    Testing ItemsStandardData
    AppearanceFlat And Smooth
    Coating ThicknessGB/T6554-200350~70mm
    Gloss(60°)GB/T9754-2007From 2%~100% to All Gloss
    Impact ResistanceGB/T1732-199350kg.cm
    Bending PerformanceGB/T6742-20072mm
    CuppingGB/T9753-20078mm
    Adhesion ForceGB/T9286-19980 Grade
    HardnessGB/T6739-20062H

    Resistant to Salt

    (1000 Hours)

    GB/T1771-2007No Change For Coating Appearance
    Humidity And Heat Resistance (1000 Hours)GB/T1740-2007No Change For Coating Appearance

    Chemical Medium Resistance (240 Hours)

    5%H2SO4

    5%HCl

    5%NaOH

    5%NaCl

    GB/T1763-1979

    No Change For Coating Appearance

    No Change For Coating Appearance

    No Change For Coating Appearance

    No Change For Coating Appearance

    Heat ResistanceGB/T1735-2009It Can Reach Between 220℃/20minutes And 240℃/40minutes According To Color And Different Requirement
